Purified Water Generation System with UF And EDI System

Name: Purified Water Generation System with UF And EDI System
Brand: CY-Water
SKU: CY-PW-2000Liter/Hour
Price: 1.00 USD
Availability: InStock
Rating: 5 (144 reviews)

Large Image : Purified Water Generation System with UF And EDI System Get Best Price

Product Details:

Place of Origin:	Made in China
Brand Name:	CY-Water
Certification:	ISO ,CE
Model Number:	CY-PW-2000Liter/Hour

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	Export Standard and Wood Package .
Delivery Time:	35 days after receiving the deposit .
Supply Ability:	10 Sets/Month

Contact Now

Detailed Product Description

Conductivity:	2--0.5 μs/cm	Recovery Rate:	>97%
RO Housing:	SS 304 316 8040 4040	Connection:	Clamp ,Welding
Power Supply:	AC 220V / AC 380V / 415V±5% 50 HZ / 60HZ	Valve Control:	Pneumatic , Manual
RO Membrane:	High Temperature Type

Product Name: Purified Water Generation System with UF And EDI System

Common Process :

1. Single RO System :The raw water tank→the raw water pump→Multi-medium filter →Activated Carbon filter→Scale inhibitor device→1st safe filter→1st High Pressure Pump→1st RO Device→Pure water tank

2. Doubel Reverse Osmosis System:The raw water tank →the raw water pump→Quartz sand filter →Activated Carbon filter→Scale inhibitor→1st security filter→1st High Pressure Pump →1st RO Device→1st RO Water tank→2nd HPP →2nd RO Device →Pure Water Tank

3. 1 st Reverse Osmosis system +EDI system:the raw water tank →the raw water pump→Quartz Sand Filter→Activated Carbon filter→Softener →1st security filter→1st HHP →1st RO Device→RO water tank →EDI booster pump →EDI device→Pure Water Tank

4. Double reverse osmosis system+EDI system:The raw water tank→the raw water pump→Quartz sand filter →Activated carbon filter→Softener→1st security filter→1st RO High pressure pump→1st RO Device→1st RO Water tank →2nd High Pressure Pump→2nd RO Device→2nd RO Water tank→EDI booster pump →→EDI Device→Pure Water Tank .

Technical Parameter:

Output Water Capacity	0.5m³/h--50m³/h
TOC	＜100PPB
Conductivity	＜0.5μs/cm
Microorganism	＜100 CFU/ml
Endotoxin	＜0.25EU/ml
Nitrate	＜0.06PPM
Heavy metal	＜0.1 PPM
