Pure Steam Generator Pharmaceutical/Pure Steam Generator Pirce /Pure Steam Generator process flow diagram

Name: Pure Steam Generator Pharmaceutical/Pure Steam Generator Pirce /Pure Steam Generator process flow diagram
Brand: CY-Water
SKU: CY-PSG-100KGS
Price: 4999 USD
Availability: InStock
Rating: 4.7 (178 reviews)

Large Image : Pure Steam Generator Pharmaceutical/Pure Steam Generator Pirce /Pure Steam Generator process flow diagram Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	CY-Water
Certification:	ISO ,CE
Model Number:	CY-PSG-100KGS

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD 4999-10000 KGS
Packaging Details:	According to export standard
Delivery Time:	With 30-40 Days
Supply Ability:	100 Sets/month

Contact Now

Detailed Product Description

Material:	SS304, SS316	Warranty:	One Year
Type:	CY-PSG-200KGS	Application:	Pharma,Disinfection,Sterilize
Capacity:	100KGS,200KGS,500KGS

Product Name: Pure Steam Generator Pharmaceutical/Pure Steam Generator Pirce /Pure Steam Generator process flow diagram

Pure Steam Quality plays a vital role in steam sterilization of load in Pharmaceutical Industry. International regulatory standards such as EN 285, EN 17665 & HTM2010 recomends steam quality testing and has defined parameters for compliance of clean steam. It is defined as the steam whose condensate meets all parameters of WFI.
It must meet the basic following physical properties.
Non-Condensable gases < 3.5%
Dryness Value >0.9%
Super Heat Value <25oC

CY-Water Spec. & Type

Type	Capacity	Feed Water	Industry Steam	Height(mm)	Length(mm)	Wide(mm)
PS100	100	115	130	2100	900	570
PS200	200	230	250	2500	900	570
PS300	300	345	370	2500	1100	680
PS400	400	460	480	2600	1100	680
PS500	500	575	173	2600	1170	720
PS800	800	920	960	3500	1775	930
PS1000	1000	1150	1200	3700	1775	930
PS2000	2000	2300	2400	4000	2030	1900
PS3000	3000	3450	3600	4850	2030	1900
PS4000	4000	4600	4800	5100	2200	2100
