Stream / Ozone Pharmaceutical Water Treatment Plant USP Grade 220V / 380V
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Conductivity: | 2--0.5 μs/cm | Standard: | FDA / CGMP / GMP / USP |
|---|---|---|---|
| EDI: | GE ,SIEMENS ,Micronix | Disinfection Type: | Stream , Ozone |
| Power Supply: | AC 220V / AC 380V / 415V±5% 50 HZ / 60HZ | Valve Control: | Pneumatic , Manual |
| Highlight: | pharmaceutical water treatment system,water treatment system in pharmaceutical industry |
||
Product Name: USP grade purified water generation system for In vitro dianostic reagent
REFERENCE CODES AND STANDARDS
| User Requirement Specification |
| Chinese Pharmacopoeia (2015 Edition) |
| U.S. Pharmacopeia(USP38) |
| European pharmacopoeia(EP9.2) |
| GMP(2010 Revised Edition) |
| National Standard on Electrical Safety |
The concept and the common effective removal methods for pyrogen:
The Pyrogen is a bacterial endotoxin ,that has a wide rang of bioactivity .The Pyrogen own heat resistance ,filterability ,water solubility, non volatility .The ordinary filtration and distillation are difficult to eliminate ,The commonly used treatment methods are reverse osmosis membrane method ,UF membrane method ,EDI Method and multi effect distillation method .
Poduct Technical Data:
| Model | Capacity (Ton/hour) | General Power(KW) | Electrical Power(50-60Hz) |
Membrane (Pic) |
Size (L*W*H) ( mm) |
Weight(Kg) |
| CY-RO-100L/H | 0.1 | 0.2 | AC220V | EC4021-800A | 690*570*1490 | 100 |
| CY-RO-300L/H | 0.3 | 2.75 | AC220V 18A / 380V 9A | ESPA4040*2 | 1550*900*1820 | 150 |
| CY-RO-500L/H | 0.5 | 2.75 | AC220V 18A / 380V 9A | ESPA4040*3 | 1550*900*1820 | 250 |
| CY-RO-700L/H | 0.7 | 4.25 | AC220V 27.5A / 380V 13A | ESPA4040*4 | 1550*900*1820 | 350 |
| CY-RO-1000L/H | 1 | 3.75 | AC220V 24A / 380V 12A | ESPA4040*4 | 1980*900*1940 | 500 |
| CY-RO-2000L/H | 2 | 4.75 | AC380V 8.8A | ESPA4040*6 | 4800*700*2050 | 700 |
| CY-RO-3000L/H | 3 | 5.75 | AC380V 10A | ESPA4040*7 | 6000*800*2200 | 800 |
| CY-RO-4000L/H | 4 | 7.5 | AC380V 12A | ESPA4040*8 | 7000*900*2400 | 1000 |
| CY-RO-5000L/H | 5 | 12.5 | AC380V 25A | ESPA8040*9 | 8000*1000*2700 | 1500 |
| CY-RO-6000L/H | 6 | 15 | AC380V 30A | ESPA4040*10 | 4300*1000*2300 | 1700 |
| CYRO-12000L/H | 12 | 19 | AC380V 35A | ESPA8040*12 | 8500*1600*1920 | 2500 |
| CYRO-15000L/H | 15 | 19 | AC380V 35A | ESPA8040*15 | 10100*1870*3000 | 4000 |
| CYRO-20000L/H | 20 | 22.5 | AC380V 45A | CPA28040*20 | 10000*1700*4200 | 4600 |
| CYRO-30000L/H | 30 | 37.5 | AC380V 68A | CPA28040*25 | 13000*1900*3500 | 6000 |
| CYRO-50000L/H | 50 | 56 | AC380V 120A | CPA28040*54 | 13500*2300*3800 | 9900 |
Note:
We would require for a raw water analysis / test report for inquiries of water treatment system for any inquiry.
For more details, please contact me directly.
Company :Shanghai ChongYang Water Treatment Equipment CO.,LTD
Email:yannili1@outlook.com
Phone:+86 15900488030
Http://www.cy-waterequipment.com
