Automatic Typical Electronic Grade Ultrapure Water Purification System with Large Capacity
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Control: | Automatical Control | Pipe Material: | UPVC , Stainless Steel |
|---|---|---|---|
| The Main Components: | Membrane ,Valve ,Pump | The Brand Of Main Components: | DOW,Hydranautics ,Grundfos ,CNP |
| Process: | Pre-treatment +RO+EDI +Polishing Resin | Water Quality: | ≧18.25 MΩ.cm |
| High Light: | ultra pure water machine,upw system |
||
Product Name:A larg capacity Ultrapure Water System for Electronics Industry
The water quality standard of electronic semi-conductor industry.
The electronic grade ultra pure water equipment we make is fully conformed to the water quality standard of ASTM in the United States ,The electronic grade water quality standard of chinese electronic industry department(18MΩ.cm,15MΩ.cm,10MΩ.cm,2MΩ.cm,0.5MΩ.cm ,five stage standard),The USA Semi-conductor pure water index,the water quality standards of Japanese integrated circuits ,the water quality standards for large scale integrated circuits at home and abroad.
The Preparation Process of Typical Electronic Grade Ultra Pure Water
- Pre-treatment ---RO Device---Water Tank---Cation Bed---Anion Bed---Mixed Bed ----Pure Water Tank ---Pure Water Pump ---UV ---Precision Mixed Bed ---Microporous Membrane Filter ---The used water point
The partial product specification:
| Type |
Capacity (M3/H) |
Pipe DN(mm) | WP(MPa) | Material | Work Method |
| CY-EO-0.5 | 0.5 | DN20 | ≤1.6 |
Stainless Steel/Carbon Steel
|
Full Automatica/Semi Automatic |
| CY-EO-1 | 1 | DN25 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-2 | 2 | DN32 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-3 | 3 | DN40 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-5 | 5 | DN50 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-10 | 10 | DN75 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-20 | 20 | DN100 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-30 | 30 | DN125 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-40 | 40 | DN150 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
| CY-EO-50 | 50 | DN200 | ≤1.6 | Stainless Steel/Carbon Steel | Full Automatica/Semi Automatic |
Note:1. Our company can customized according to customer requirements.if customers have any question please contact us in time .
2. Our company keep to revise right at any time ,the company will not be notified if amended.
