SS316L Multi Column Distillation Plant Four Effects Distilled Water Making Machine For In Vitro Diagnostic Reagent

Name: SS316L Multi Column Distillation Plant Four Effects Distilled Water Making Machine For In Vitro Diagnostic Reagent
Brand: CHONGYANG
SKU: CY-WFI-300Liter/Hour
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (177 reviews)

Large Image : SS316L Multi Column Distillation Plant Four Effects Distilled Water Making Machine For In Vitro Diagnostic Reagent Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	CHONGYANG
Certification:	ISO ,CE
Model Number:	CY-WFI-300Liter/Hour

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	Export standard
Delivery Time:	With 30-40 Days
Payment Terms:	L/C, T/T
Supply Ability:	100 Sets/Months

Contact Now

Detailed Product Description

Material:	SS316L	Stages:	4-6 Effects
Conductivity:	1.3μS/cm	Requested Feed Water:	Purified Water System
Standard:	FDA,USP,cGMP,GMP	Pipeline Material:	BPE,SS C

Product Description

Product Name:Four Effects Distiller Water For Injection Water Machinery For In Vitro Diagnostic Reagent

CHONGYANG WATER FEATURE:

PREHEATER:

Pre-heater is mainly used for heating for feed water to raise temperature of feed water as much as possible to improve evaporation effect ,meanwhile the distilled water is cooled down by the low temperature of the feed water ,it have double effect.

Central Electric Control Cabinet :

The system is equipped with independent central electric control cabinet on master frame for operation &monitor of the system . There are all element in the cabinet ,such as power supply ,switch ,bottom , relay ,contactor ,indicator light ,VFD . It is easy to check and operate .the weak current and strong current are designed separately and installed in the different control cabinets .

CHONGYANG Water Spec. & Type

Model	Effects	Capacity	Feed Water	Plant Steam	Cooling Water	Height (mm)	Length (mm)	Width (mm)
CY-WS100	4	100	115	45	80	2650	1300	710
CY-WS200	4	200	230	76	120	2650	1360	710
CY-WS200	5	200	230	62	50	2650	1620	710
CY-WS300	4	300	345	109	190	2650	1410	730
CY-WS300	5	300	345	89	90	2650	1730	730
CY-WS500	4	500	575	185	310	3170	1680	900
CY-WS500	5	500	575	148	130	3170	2000	900
CY-WS750	4	750	865	256	300	3260	1680	900
CY-WS750	5	750	865	205	178	3260	2000	900
CY-WS1000	5	1000	1150	295	256	3685	2180	980
CY-WS1000	6	1000	1150	245	65	3685	2830	980
CY-WS1500	5	1500	1725	460	390	3685	2680	1100
CY-WS1500	6	1500	1725	380	95	3685	3150	1100
CY-WS2000	5	2000	2300	540	345	3940	3150	1100
CY-WS2000	6	2000	2300	490	130	3950	3580	1100
CY-WS3000	6	3000	3450	730	190	4050	4000	1200
CY-WS4000	6	4000	3450	910	310	4800	4000	1200
CY-WS5000	6	5000	5750	1140	440	4200	4550	1350
