High Efficiency Reverse Osmosis Seawater Treatment Plant for Industrial Desalination and Water Purification
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Water Source: | Seawater | Technology: | Reverse Osmosis RO |
|---|---|---|---|
| RO Membrane Brand: | DOW / Toray / Hydranautics | Product Water Capacity: | 500L/H – 100m3/h |
| Desalination Rate: | ≥99.5% | Recovery Rate: | 35% – 45% |
| Product Water TDS: | ＜500 Ppm | Feed Water Salinity: | ≤45000 Ppm |
| High Pressure Pump: | Grundfos/CNP | Pretreatment System: | Sand Filter + Carbon Filter |
| Membrane Housing: | FRP / SS316L | Voltage: | 220V / 380V / 415V |
| Certification: | ISO / CE / SGS |
Solar Powered SWRO | Solar Powered Desalination System for Remote Marine & Island Water Supply
Introduction
A Solar Powered SWRO system is an advanced renewable-energy seawater desalination solution designed to convert seawater into freshwater using solar power. The solar powered desalination system combines photovoltaic energy technology with seawater reverse osmosis technology to provide sustainable drinking water for remote islands, coastal villages, offshore facilities, resorts, fishing communities, militar bases, and marine engineering projects.
The system reduces diesel fuel consumption, lowers operational costs, and enables stable freshwater production in areas with limited power infrastructure. Typical capacities range from 1 TPD to 500 TPD depending on solar conditions and project requirements.
What Is This Solar Powered SWRO System?
A Solar Powered SWRO system is a seawater desalination plant powered fully or partially by solar photovoltaic energy. The system uses solar panels to generate electricity that drives the seawater reverse osmosis desalination process.
Compared with traditional diesel-powered desalination plants, a solar powered desalination system provides lower energy consumption, reduced operating costs, sustainable water production, reduced carbon emissions, stable operation in remote locations, and minimal infrastructure requirements.
The solar powered SWRO system generally includes solar photovoltaic panel array, solar inverter system, battery energy storage system, seawater intake system, pretreatment filtration unit, high-pressure pump, SWRO membrane desalination unit, PLC automatic control system, freshwater storage tank, energy recovery device, and monitoring protection system.
The solar photovoltaic system provides electricity to the desalination unit during daytime operation. Optional battery storage systems allow nighttime operation and improve system stability.
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Solar Powered SWRO |
| System Type | Solar Powered Desalination System |
| Water Source | Seawater |
| Capacity Range | 1–500 TPD |
| Product Water Standard | Drinking Water |
| Desalination Technology | SWRO |
| Energy Source | Solar PV + Optional Grid/Diesel |
| Salt Rejection Rate | ≥99% |
| Product Water TDS | ≤500 ppm |
| Recovery Rate | 35–45% |
| Solar Panel Type | Monocrystalline PV |
| Battery System | Lithium / Gel Optional |
| Pretreatment | MMF + ACF + Cartridge Filter |
| Membrane Type | SWRO Membrane |
| High Pressure Pump | SS316 / Duplex |
| Energy Recovery Device | PX / Turbocharger Optional |
| PLC Control | Schneider Optional |
| Operation Mode | Fully Automatic |
| Monitoring System | Pressure / Flow / Conductivity |
| Freshwater Tank | Optional |
| Cleaning System | CIP Optional |
| Structure Type | Skid Mounted / Containerized |
| Piping Material | UPVC / SS316L |
| Power Backup | Diesel Generator Optional |
| Installation Environment | Marine / Island / Coastal |
Features & Advantages
1. Renewable Energy Desalination
The solar powered SWRO system uses clean solar energy to reduce electricity consumption and operational costs.
2. Reduced Diesel Dependency
The system minimizes fuel transportation and diesel generator operating expenses for remote projects.
3. Environmentally Friendly Operation
Solar powered desalination significantly reduces carbon emissions and supports sustainable water production.
4. Fully Automatic PLC Control
The intelligent PLC system provides automatic operation, alarm protection, and remote monitoring capability.
5. High Salt Removal Efficiency
Advanced SWRO membranes ensure excellent desalination performance and stable freshwater quality.
6. Modular Compact Design
The skid-mounted and containerized structure simplifies transportation and onsite installation.
7. Low Maintenance Requirements
Optimized pretreatment and membrane protection reduce maintenance frequency and operational downtime.
8. Flexible Hybrid Power Integration
The system can operate with solar energy, diesel generators, grid power, or hybrid combinations.
Application Industries
Remote Island Water Supply
The solar powered desalination system provides sustainable freshwater production for islands without stable power infrastructure.
Coastal Communities
Coastal villages and communities use solar powered SWRO systems for safe drinking water supply.
Fishing Villages
Fishing harbors and marine communities require reliable freshwater production for daily operations.
Eco Resorts & Hotels
Eco-tourism facilities use solar desalination systems to reduce energy consumption and environmental impact.
Offshore Engineering Projects
Temporary offshore construction sites require mobile renewable freshwater production systems.
Militar & Emergency Applications
Solar powered SWRO systems support emergency freshwater supply and remote militar operations.
Marine Aquaculture
Aquaculture projects use desalinated freshwater for process support and facility operation.
Disaster Relief Projects
Portable solar desalination units can rapidly provide drinking water in disaster-affected areas.
Production Process
Water Treatment Process
Seawater Intake
→
Raw Water Pump
→
Multi-Media Filter
→
Activated Carbon Filter
→
Cartridge Filter
→
High Pressure Pump
→
SWRO Membrane System
→
UV Sterilization
→
Freshwater Tank
→
Water Distribution
Solar Power Process
Solar PV Panels
→
Solar Inverter
→
Battery Storage
→
PLC Control Cabinet
→
SWRO Operation
Optional Configurations
- Solar photovoltaic array
- Lithium battery storage system
- Hybrid diesel backup system
- Containerized structure
- Remote monitoring system
- Automatic membrane flushing
- PX energy recovery device
- UV sterilization system
- Ozone sterilization system
- Freshwater mineral balancing
- Stainless steel piping
- Marine corrosion-resistant coating
- Variable frequency drive (VFD)
- Automatic CIP cleaning system
- Online water quality monitoring
- Touch screen HMI interface
Why Choose CHONGYANG WATER
CHONGYANG WATER is a professional manufacturer of seawater desalination systems and renewable-energy water treatment solutions for marine, island, offshore, and industrial projects worldwide.
Our Advantages
- Professional seawater desalination engineering experience
- Advanced solar desalination integration capability
- Customized renewable energy solutions
- Stable SWRO membrane technology
- Factory pre-assembly and testing
- Flexible modular design
- Export experience worldwide
- Remote technical support
- OEM & ODM support
- Turnkey desalination engineering services
CTA
Looking for a reliable Solar Powered SWRO manufacturer? CHONGYANG WATER provides customized solar powered desalination systems, marine SWRO plants, renewable-energy seawater treatment solutions, and turnkey freshwater production systems for global marine and island projects.
Contact our engineering team today for process design, technical consultation, and competitive quotations for your solar desalination project.
