Pure Steam Generator In Pharmaceutical Industry

Large Image : Pure Steam Generator In Pharmaceutical Industry Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	CY-Water
Certification:	ISO, CE
Model Number:	CY-PS-100KGS

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	USD 4999-10000 KGS
Packaging Details:	According to export standard
Delivery Time:	45 Days
Payment Terms:	L/C, T/T
Supply Ability:	100 Sets/month

Contact Now

Detailed Product Description

Capacity:	100KGS-500KGS

Product Name:Pure Steam Genrator in Pharmaceutical Industry

Working principle:

The qualified raw water is input into the branch of condenser after increased the pressure by multilevel pump,and then enter into the separator and evaporator.The level is controlled by level switch.After entering the evaporator ,the industrial steam is heating raw water to evaporation temperature,and then form into strong heat cycle in the evaporation room and separation room ,After vaporizing ,raw water changes into steam which enters into the separator with water drops .Those water drops will be detached from the steam and enter into raw water at the effect of gravity in the separation device which fixed at the top of separator ;it will produce ultra purified steam at the top of separator.

Industrial steam input working pressure:0.3MPa

Pure steam working pressure:0.15-0.2MPa

CY-Water Spec. & Type:

Type	Capacity	Feed Water	Industry Steam	Height(mm)	Length(mm)	Wide(mm)
PS100	100	115	130	2100	900	570
PS200	200	230	250	2500	900	570
PS300	300	345	370	2500	1100	680
PS400	400	460	480	2600	1100	680
PS500	500	575	173	2600	1170	720
PS800	800	920	960	3500	1775	930
PS1000	1000	1150	1200	3700	1775	930
PS2000	2000	2300	2400	4000	2030	1900
PS3000	3000	3450	3600	4850	2030	1900
PS4000	4000	4600	4800	5100	2200	2100
